Wi - Fi Camera 4G Alarm System With Wireless Smart PIR Door Detector Siren

4G Alarm System With Wi-Fi Camera Wireless Smart PIR Door Detector siren

Feature

•  Creates Wi-Fi AP for Wi-Fi cameras and others Wi-Fi devices to connect 3G/4G network
•  Wireless trigger Wi-Fi camera push video to user cell phone when alarm
•  32 Wireless Zones, Normal/Bypass mode and Zone Name is editable, 3 24-Hour zones for Panic button, smoke and gas leakage detector
•  Smart wireless PIR and door detector, support disconnect alarm , low battery alarm, power level feedback, door detector not ready remind, Individual name for each detector
•  Support 4 wireless siren
•  Intelligent arm and disarm by schedule
•  SMS notifications when any family arm or disarm
•  Can set 21:00pm to 07:00am night-silence mode
•  Smart temperature control and temperature low or high alarm.
•  Support power failure and recover SMS alerts.
•  Support 10 cell phone numbers receive alarm
•  Setting by sms command, e.g. remote add/edit/delete phone group
•  Operate by sms command, e.g. armed, Bypass armed or disarmed by SMS
•  Control outputs by sms commands
•  Supports timed task
•  Standby internal rechargeable battery which can last 10 hours
•  Automatically update internal clock via sms
•  Time stamped in alarm or recover messages
•  GPS selectable
•  Easy used GUI configure software

Interface

•  4 Wired Zones(digital inputs), NC/NO, and Zone Name is editable
•  Siren out with 3.5mm jack
•  1 OC outputs (open-collector)
•  1 relay output (3A, 220Vac)
•  1 temperature detector input, monitor rang: -55℃-125℃
•  1 USB to connect PC to setup by configure software
•  GSM antenna SMA connector(50 Ω)×1
•  433MHz antenna SMA connector×2
•  Wi-Fi antenna SMA connector(50 Ω)×1

Specifications

•  FDD LTE: B1/B3/B5/B7/B8/B20 (UMTS: B1/B5/B8 GSM: 850/900/1800/1900MHz)
•  DC Power supply: 12VDC 1.5A
•  Power consumption: 12V input Max. 150mA/Average 50mA
•  SIM Card: Supporting 3V SIM Card
•  Antenna: 50 Ω SMA Antenna interface
•  Working temperature: -20℃~+60℃
•  Relative humidity: 10-90%, No condensation
•  Wireless detector receiving frequency: 433MHz
•  Effective distance of wireless transmission: 150m (Open area)
•  Aluminum body
•  Exterior dimension: 120×85×28mm
•  Weight: 285g

Standard package

•  Host X1
•  4G antennaX1
•  RF antennaX2
•  Wi-Fi antennaX1
•  USB cable X1
•  AC/DC AdaptorX1
